500 Liters Rotating Column Alembic COMPLETE

🛢️ 500 Liters Rotating Column Alembic COMPLETE

Introducing the 500 liters Rotating Column Alembic, a model that combines elegant design, durability, and efficiency to achieve professional results in every distillation. Made from high-quality copper with a hammered finish and polished brass details, this alembic ensures uniform, safe, and stable distillation. Its rotating column system with hinge allows for easy emptying and reloading of the column, achieving 3 to 5 loads per distillation to maximize performance.

✨ Main Features:

• 🔹 Boiler: 500 liters
• 🔹 Column: capacity for 80-90 kg of plants or flowers per load
• 🔹 Hinge: facilitates emptying and reloading the column
• 🔹 Includes: thermometer (0–120º) + column separation grid + boiler separation grid + 70 cm gas grill + liquid outlet on the boiler with 2.5″ stainless steel or brass valve + iron supports on the boiler and condenser
• 🔹 Material: 2.5 mm copper sheet with hammered finish
• 🔹 Details: polished brass handles and nuts
• 🔹 Joints: welded for greater strength and durability
• 🔹 Complete system: ideal for continuous, controlled distillation with gas

📊 Output per distillation:

• 🌿 Plants/Flowers: 270-400 kg (with 3 to 5 column loads)
• 💧 Hydrosol: 450-475 liters
• 🛢️ Essential oil: 1.5-2 liters of pure essential oil

🧪 Applications:

• 🌸 Distillation of aromatic plants and flowers
• 🍹 Alcohol distillation
• 💧 Production of aromatic hydrosols
• 🛢️ Extraction of high-quality essential oils
